LINOCROME

Application areas

Waterproofing of roofs. Repair of roof cladding. Vapor proofing.

Method of application

The material is welded on a prepared surface using a gas burner. Material application: according to the Manual for Designing and Installation of Roofs Made of Bitumen Materials Manufactured by the TechnoNICOL Company.

Description of material

Linocrome is a waterproofing sheet produced by two-sided installation of bitumen binder on a dense rot-proof base. This material has been used for many years and is a successful solution for low-budget projects.

Linocrome K is applied as the top layer of roof cladding. Coarse-grained dressing compound on the face side protects the material against sunlight.

Linocrome P is applied as the vaporproofing bottom layer of roof cladding. A fi ne-grained dressing compound or a polymer film can be used as a protective layer.

Linocrome can be used in all climatic zones (as determined in Construction Codes and Regulation (SNiP) 23-01-99*).

Storage

  • Store vertically, in a place protected from direct sunlight.
  • Many years of successful application
  • Service life — 7-10 years

Types of material

  • EPP
  • TPP
  • HPP
  • EKP
  • TKP
  • HKP

Specifications:

Property   EPP TPP HPP EKP TKP HKP
Mass of 1 m2, kg, (±0.25 kg)   3,85  3,85  3,85  5,1  5,2  5,1
Longitudinal/transverse breaking load, N, not less than  polyester  343/-  –  –  343/-  –  –
fiberglass  –  800/900  –  –  800/900  –
fiberglass mat  –  –  294/-  –  –  294/-
Bend point on R=25 mm beam, °C, no more than   0  0  0  0  0  0
Heat endurance, °С, not less than   85  85  85  85  85  85
Protective covering type  on the top  film without logo  film without logo  film without logo  granulated material, slate  granulated material, slate  granulated material, slate
on welded-on side  film with logo  film with logo  film with logo  film with logo  film with logo  film with logo
Length / width, m   15х1  15х1  15х1  10х1  10х1  10х1
